Micromotori brushless coreless 2 poli

Serie ATOM HS

Tipicamente utilizzati in campo medico per gli strumenti chirurgici, questi motori uniscono le caratteristiche della serie SVTN A ad un design progettato per raggiungere alte velocità. Grazie al bilanciamento preciso del rotore e all’uso di cuscinetti speciali, sono garantite massima stabilità e silenziosità.

Specifiche tecniche

  • Da 16 a 20 mm di diametro
  • Alta velocità fino a 80Krpm

Attributi

Alta velocità
Bassa inerzia
Silenziosi
Coreless
Personalizzabile
Alta efficienza

Download

Micromotors-v3.1
SVTN A 02 Series
brand

Serie ATOM HS

Tipicamente utilizzati in campo medico per gli strumenti chirurgici, questi motori uniscono le caratteristiche della serie SVTN A ad un design progettato per raggiungere alte velocità. Grazie al bilanciamento preciso del rotore e all’uso di cuscinetti speciali, sono garantite massima stabilità e silenziosità.

Attributi

Alta velocità
Bassa inerzia
Silenziosi
Coreless
Personalizzabile
Alta efficienza

Specifiche tecniche

  • Da 16 a 20 mm di diametro
  • Alta velocità fino a 80Krpm

Download

Micromotors-v3.1
SVTN A 02 Series

ValuesUnit1636-24..1636-30..1636-36..
Nominal voltageV243036
No load speedrpm402734022540760
No load currentmA907772
Nominal speedrpm370673695837406
Nominal torquemNm555
Nominal currentA0,980,790,67
Stall torquemNm62,861,660,8
Stall currentA11,28,87,3
Max. efficiency%82,982,281,2
Terminal resistance*Ω2,143,414,9
Terminal inductance*mH0,110,170,24
Torque constantmNm/A5,657,068,35
Speed constantrpm/V169213531143
Speed/torque gradientrpm/mNm641653671
Mechanical time constantms3,73,83,9
Rotor inertiagcm20,550,550,55
Thermal resistance housing-ambientK/W18.618.618.6
Thermal resistance winding-housingK/W3.443.443.44
Thermal time constant windings666
Thermal time constant motors298298298
Ambient temperature°C-30…+100-30…+100-30…+100
Max. permissible winding temperature°C+150+150+150
Max. permissible speedrpm800008000080000
Radial playpreloadedpreloadedpreloaded
Max. axial load (dynamic)N2.52.52.5
Max.force for press fits (static)N444444
Max. radial loading, 5mm from flangeN111111
Number of poles222
Number of phases333
Weightg323232
